Ortofon OM SCRATCH ON SH4

Core Performance Features

• Factory Pre-Mounted & Aligned: Ships pre-assembled and calibrated to standard 52 mm Technics overhang geometry, allowing immediate plug-and-play connection to any SME bayonet socket.

• Reinforced Scratch Cantilever: Built with an extra-durable suspension and stiff cantilever assembly engineered to resist skipping during rapid backcueing, hard cuts, and aggressive finger manipulation.

• High-Output 7 mV Generator: Delivers a hot 7 mV signal to DJ mixer phono preamps, providing strong dynamic range, high signal-to-noise ratio, and pronounced low-end punch on club sound systems.

• Groove-Preserving Spherical Diamond: Features a precision spherical diamond tip that sits higher in the groove, minimizing record burn and premature groove wear during repetitive cue-point scratching.

• Ergonomic Long Finger Lift: The SH-4 aluminum headshell features an extended, curved finger lift that gives DJs steady, slip-free control when needle-dropping in low-light booths.

• DVS & Real Vinyl Tracking: Fully optimized for clean signal tracking across both traditional analog vinyl and timecode control records (rekordbox, Serato DJ, Traktor Scratch).

Technical Layout & Specifications

• Package Contents: 1 x Ortofon OM Scratch Cartridge pre-mounted on 1 x Ortofon SH-4 Headshell (Black).

• Cartridge Type: Moving Magnet (MM).

• Mounting Connection: Universal SME 4-pin bayonet.

• Stylus Profile: Spherical (R 18 µm).

• Output Voltage: 7 mV (@ 1 kHz, 5 cm/sec).

• Frequency Response: 20 Hz – 20,000 Hz.

• Tracking Force Range: 3.0 g – 5.0 g (30 – 50 mN).

• Recommended Tracking Force: 4.0 g (40 mN).

• Tracking Ability: 80 µm (@ 315 Hz at recommended tracking force).

• Channel Separation: 20 dB (@ 1 kHz).

• Internal Impedance / DC Resistance: 750 Ohms.

• Internal Inductance: 450 mH.

• Recommended Load Resistance: 47 kOhms.

• Recommended Load Capacitance: 200 – 600 pF.

• Total Assembly Weight: ~14.4 g (Cartridge 5.0 g + Headshell 9.4 g).
